Local Laws 92 and 94 of 2019 require sustainable roofing systems for new constructions, existing roof expansions and roof replacements. Under these laws, sustainable roofing is defined as a solar photovoltaic system, a green roof, or a combination of both.
We can help you meet Local Laws 92 and 94 of 2019.
This blog post provides a practical guide on how to meet LL 92 & 94 of 2019, summarizing the key points contained in the laws.
Calculating the Roof Area Covered by LL92 & 94
To determine how much sustainable roofing area you need, the following areas must be subtracted from the total roof area:
FDNY Roof Access: At least 6 feet x length of building x depth of building;
HVAC equipment, roof structures, towers, parapets, guardrails, solar thermal systems and associated accessories;
Terraces not exceeding 25% of the largest floor plate area in the building;
Recreational spaces that are principal to the building’s use.
It must be noted that the exception for recreational spaces principal to the building’s use is ill-defined by the law.
When all these areas are subtracted from the total roof area, whatever is left is considered the “sustainable roofing zone” under LL92 & 94.
Deciding Between Solar PV Systems and Green Roofs
After identifying which areas require sustainable roofing, the next step is deciding between adding solar panels and installing a green roof. Solar panels are only compliant if they can generate at least 4 kilowatts of capacity; otherwise, a green roof must be used.
If the sustainable roofing zone is less than 200 square feet, it may be the case for using a green roof instead of solar panels. A solar power design requires a professional assessment, but consider the following rule of thumb for estimation purposes:
A 3’ x 5.5’ solar panel offers you around 350 W, using an area of 16.5 square feet;
12 panels will get you 4200 W of capacity;
12 panels require around 198 square feet of unobstructed roof space.
If the project owner wishes to use solar panels, and the sustainable roofing zone is smaller than 200 sq.ft., higher efficiency and more expensive solar panels are needed to reach 4 kW.
A Few Things to Consider
The cost of meeting LL92 & 94 can be reduced with smart design decisions. The following are some viable strategies:
HVAC equipment can be lawfully extended, using all clearances possible, to reduce the sustainable roofing zone;
In cases where a solar thermal system is cheaper than a solar photovoltaic system, this system can also be used to reduce the sustainable roofing zone;
In low-cost projects where the sustainable roofing zone is less than 200 square feet, the area can become exempt by using a roof detention system with a slope above 17%, as per the 2014 BC Section 1511.2, exception No. 5: "A roof assembly with a slope greater than two units vertical in 12 units horizontal (17 percent) that would accommodate less than 4kW of solar photovoltaic electricity generating capacity."
To find the best compliance option for your building, a professional assessment from a qualified engineering firm is recommended. By optimizing the layout of your roof and its equipment, the area covered by LL92 & 94 can be minimized.
