Designing Residential Buildings for Natural Ventilation

Topics: Design, Building Code, new york

Chelsey Bipat
Author : Chelsey Bipat on September 6, 2018

Residential buildings in New York City are often designed to achieve optimal indoor conditions with mechanical ventilation alone. However, the NYC Building Code makes natural ventilation design mandatory even in these cases. Modern construction is characterized by a trend toward airtight buildings, where the goal is to minimize heat loss in the winter and heat gain in the summer. However, poor natural ventilation creates two limitations for occupants.

  • In a building that is not designed for 100% natural ventilation, mechanical ventilation cannot be turned off to save energy.
  • In any situation where the mechanical ventilation systems is rendered inoperable, the building cannot sustain adequate indoor conditions for an extended period.

Natural ventilation design contributes to energy efficiency in residential spaces, while ensuring a supply of fresh air even without a mechanical ventilation system. Section 1203 of the NYC Building Code allows property owners to deploy natural and mechanical ventilation independently or simultaneously. However, the code clearly states that natural ventilation is mandatory for any indoor location classified as habitable space by the NYC Building Code.

It is important to note that natural ventilation is only recognized as such by the NYC Building Code if achieved with openings leading directly outdoors, not to other building areas.

What is Habitable Space?

Habitable space refers to indoor areas in buildings classified under occupancy Groups R and I-1. The term includes bedrooms, living rooms and dining rooms. Inside these occupancies, the only rooms not considered habitable spaces by the NYC Building Code are the following:

  • Dining spaces up to 55 ft2 located next to a kitchen, living room or foyer
  • Kitchens below 80 ft2, also known as kitchenettes
  • Bathrooms and toilet rooms
  • Laundries
  • Corridors or hallways used as an entrance, as long as they don’t exceed 10% of total floor area. If rooms are at least 20% above the minimum area established in the NYC Housing Maintenance Code, hallway area can be up to 20% of total floor space without being considered habitable space.

In all habitable spaces, the operating mechanism for windows or other openings leading outdoors should be readily accessible by occupants. Limiting devices should only be used in healthcare facilities where the NYC Health Code requires them, and they must be removable with authorization.

Occupiable space refers to indoor locations designed for human occupancy but not classified as habitable space. These locations are used for purposes such as working, dining and education. In these cases, natural ventilation is only mandatory when mechanical ventilation is made optional by the NYC Building Code.

Natural Ventilation Requirements for Habitable Space

The openable area leading outdoors in habitable space must be at least 5% of total floor area. In addition, every opening must have a glazed area of at least 12 ft2, and an openable area of at least 6 ft2. These requirements apply individually for each room, even when the rooms in question are connected by doors, wall openings or internal windows.

In the case of mezzanines and split-level rooms, the additional area must also be considered for natural ventilation calculations. Alcoves in R-3 occupancies can be ventilated through another room, but only if the opening that leads to them is at least 80% of total wall area, and their floor area does not exceed twice the opening area. Natural ventilation openings that lead to balconies are allowed, as long as the balcony itself meets the ventilation requirements specified in the NYC Building Code.

Bathrooms in Group R or I-3 buildings are subject to mandatory natural ventilation requirements unless they have exhaust ventilation compliant with the NYC Mechanical Code.

  • Natural ventilation must be accomplished with windows, but skylights are also allowed if the bathroom is in the top floor of a building.
  • The minimum openable area required is 5% of floor space, where each window or skylight must have at least 3 ft2 in total and 1.5 ft2 of openable area.
  • Natural ventilation openings in bathrooms can open towards closed balconies only if no other rooms use the for mechanical ventilation.
  • Outside or Group R or I-3 buildings, mechanical ventilation becomes mandatory for all bathrooms, even if they are designed for natural ventilation.

Kitchenettes are subject to similar requirements as bathrooms, requiring natural ventilation unless they are equipped with exhaust ventilation according to the NYC Mechanical Code. The openable area requirements are the same as in bathrooms: 5% of total floor area, at least 3 ft2 glazed area per window or opening, and 1.5 ft2 of openable area. Windows are required, but skylights are allowed for kitchenettes in a top floor.

Natural Ventilation and Energy Efficiency

One reason why the NYC Building Code makes natural ventilation mandatory in habitable spaces is to give occupants flexibility in how ventilation is accomplished. Although a well-designed mechanical ventilation system provides the required air changes per hour, some occupants may decide to open the windows instead due to personal preference or to save energy. Deactivating the mechanical ventilation system and opening the window may also reduce the need for air conditioning under some weather conditions, delivering additional energy savings.

Natural Ventilation and Safety

Natural ventilation systems are also a safety measure when the power supply is interrupted for an extended period due to a power grid issue or harsh weather. Hurricane Sandy in 2012 was an example of this, leaving around 20% of New York City without electricity. Since evacuating such a large population is very difficult, buildings must be able to provide adequate shelter, and this includes providing adequate natural ventilation when mechanical ventilation systems are unavailable.

Summary

Residential building interiors and other habitable spaces in NYC are subject to specific ventilation requirements. The main difference with other building interiors is that natural ventilation becomes mandatory even if the building is designed to operate exclusively with mechanical ventilation. Property management companies can ensure their ventilation systems meet NYC codes by getting in touch with a professional engineering consultant or design firm.

Although mechanical ventilation is optional in many cases, this does not mean the system is exempt from codes. Installing the system is optional, but if a property management company decides to do it, meeting the requirements of the NYC Mechanical Code is still mandatory.
